1 kVA
2 kVA
3 kVA
4 kVA
5 kVA


1 kVA

Model

YS1200-LPG

Rated frequency (Hz)

50/60

Rated voltage (V)

110/120/220/230/240

Rated output power (kVA)

1.0

Rated speed (rpm)

3600

DC output

12V / 8.3A (option)

Power factor (cos¦Õ)

1

Phase

Single-phase

Noise level [dB(A)/7m]

65~67

Packing size (L¡ÁW¡ÁH) (mm)

460¡Á410¡Á390

Net weight (kg)

42

Structure model

Open-frame

Engine model

YS154LPG

Engine type

 Single-cylinder, 4-stroke, air-cooled,
OHV, GAS engine

Max.Output [ (HP)/rpm]

2.5 / 3600

Starting system

Recoil starter

Brand of Starting Motor

made in shanghai china

Oil capacity (L/gal)

0.6/0.16

Fuel type

Liuefied petroleum GAS

Lube brand

SAE15W40 (above CC grade)

Low oil pressure alarm system

With
20¡¯¡¯FCL(set) 480
TOP
2 kVA


Model

YS2000-LPG

Rated frequency (Hz)

50/60

Rated voltage (V)

110/120/220/230/240

Rated output power (kVA)

2.0

Rated speed (rpm)

3600

DC output

12V / 8.3A (option)

Power factor (cos¦Õ)

1

Phase

Single-phase

Noise level [dB(A)/7m]

65~67

Packing size (L¡ÁW¡ÁH) (mm)

565¡Á440¡Á470

Net weight (kg)

48

Structure model

Open-frame

Engine model

YS168LPG

Engine type

Single-cylinder, 4-stroke, air-cooled,
OHV, GAS engine

Compression ratio

8.5:1

Max.Output [ (HP)/rpm]

5.0 / 3600

Starting system

Recoil starter

Brand of Starting Motor

made in shanghai china

Oil capacity (L/gal)

0.6/0.16

Fuel type

Liuefied petroleum GAS

Lube brand

SAE15W40 (above CC grade)
Low oil pressure alarm system With
20¡¯¡¯FCL(set) 250
TOP
3 kVA


Model

YS3000-LPG

Rated frequency (Hz)

50/60

Rated voltage (V)

110/120/220/230/240

Rated output power (kVA)

3.0

Rated speed (rpm)

3600

DC output

12V / 8.3A (option)

Power factor (cos¦Õ)

1

Phase

Single-phase

Noise level [dB(A)/7m]

65~67

Packing size (L¡ÁW¡ÁH) (mm)

565¡Á440¡Á470

Net weight (kg)

48

Structure model

Open-frame

Engine model

YS170LPG

Engine type

Single-cylinder, 4-stroke, air-cooled,
OHV, GAS engine

Max.Output [ (HP)/rpm]

6.0 / 3600

Starting system

Recoil starter

Brand of Starting Motor

made in shanghai china

Oil capacity (L/gal)

0.6/0.16

Fuel type

Liuefied petroleum GAS

Lube brand

SAE15W40 (above CC grade)

Low oil pressure alarm system

With
20¡¯¡¯FCL(set) 250
TOP
4 kVA


Model

YS5000-LPG

Rated frequency (Hz)

50/60

Rated voltage (V)

110/120/220/230/240

Rated output power (kVA)

4.0

Rated speed (rpm)

3600

DC output

12V / 8.3A (option)

Power factor (cos¦Õ)

1

Phase

Single-phase

Noise level [dB(A)/7m]

70~75

Packing size (L¡ÁW¡ÁH) (mm)

600¡Á450¡Á470

Net weight (kg)

78

Structure model

Open-frame

Engine model

YS182LPG

Engine type

Single-cylinder, 4-stroke, air-cooled,
OHV, GAS engine

Compression ratio

08:01

Max.Output [ (HP)/rpm]

10.0 / 3600

Starting system

Recoil starter

Brand of Starting Motor

made in shanghai china

Fuel tank capacity (L)

25.8

Fuel type

Liuefied petroleum GAS

Lube brand

SAE15W40 (above CC grade)
Low oil pressure alarm system With
20¡±FCL (set) 135
TOP
5 kVA


Model

YS6500-LPG

Rated frequency (Hz)

50/60

Rated voltage (V)

110/120/220/230/240

Rated output power (kVA)

5.0

Rated speed (rpm)

3600

DC output

12V / 8.3A (option)

Power factor (cos¦Õ)

1

Phase

Single-phase

Noise level [dB(A)/7m]

70~75

Packing size (L¡ÁW¡ÁH) (mm)

600¡Á450¡Á470

Net weight (kg)

86

Structure model

Open-frame

Engine model

YS188LPG

Engine type

Single-cylinder, 4-stroke, air-cooled,
OHV, GAS engine

Compression ratio

08:01

Max.Output [ (HP)/rpm]

12.0 / 3600

Starting system

Recoil starter

Brand of Starting Motor

made in shanghai china

Fuel tank capacity (L)

25.8

Fuel type

Liuefied petroleum GAS

Lube brand

SAE15W40 (above CC grade)
Low oil pressure alarm system With
20¡±FCL (set) 135
TOP
