Cleaning and disinfection washing machine |
| Note:Catalog is PDF format:Download Software(PDF Reader) |
|
| ------- Advanced technology in the world, ideal for medical use |
Advantage:
- The advanced design for Dual door interlocking
The two doors opening, front door for the washing material in, back door for the cleaned material out. The two doors can not be opened at the same time, which make a safety curtain between the clean area and the dirty area, avoid the crossing infection for the cleaned material if it is
out from one single door.
- Automatic control of the whole process of washing
PLC control, precise, stable, reliable, touching screen display, easy operating, parameter-time display, direct-viewing
- Good cleaning capacity
The pipeline and deep interior part of the objects can be cleaned
- High efficiency of HEPA filtering, can reach million degree of filtration, which is the best cleaning degree in the world.
- Spraying and drying
Unique rotary jet can spray under-heavy pressure ejecting from any angle, high efficiency drying system can dry completely
- Drying temperature and washing temperature can be changed during the working to get the most suitable washing condition, it is unique function which other equipments not have.
- A0 value display, which conforms to ISO15583, the heat disinfection situation of the objects can be observed at any time. It is unique function which other equipments not have.
- Alarm display automatically, which can make operator know the reason directly why such mistakes caused
|
| |
| |
|
Technical specification:
- Exterior Dimensions (W x D x H mm): 930×700×1840
- Effective Washing Area (W x D x H mm): 600×630×820
- Standard Cleaning Shelve: 4 layer (disassemble), 8 standard cleaning basket
- Cleaning basket dimension（L×W×H mm）: 485×280×64
- Washing capacity: 4~8 surgeries
- Weight: 240㎏
- Structure: vertical stand
- Door and opening mode: double door, by hand
|
|
- Voltage: AC 380V
- Heating method: electrical heating
- Total power: 20KW
- Washing temperature: normal temperature to 93 ℃ (adjustable)
- Connection dimension: diameter of cool water & pure water inputting is 20mm, inputting pressure 0.03～08MPa
- Drainpipe diameter: φ51
- Vent-pipe diameter: φ63
- Program memory: six standard and one self-cleaning programs, 53 programs can be storaged
- 30min Self-cleaning working time: 30min
- Drying temperature: 70～100℃
- Cleaning cabinet material: sus304
- Water consume: 15liter/every cycle
- Electricity consume: standard program 9.8KW.h
- Enzyme consume: 80ml/cycle
- Oil consume: 20ml/cycle
- Displayer: color liquid crystal touchable screen in English
- Water heating rate: 10℃/min
- Password set: Password safety
- Accessories for selected: shelves for flasks, test tubes, breakers, Petri dishes, shelve for clean medical containers and shelve for endoscopes
- Noise: 60dBa Max
- A0 value real time display
- Applying area: breath pipes, plastic material tools, medical containers, flasks, test tubes, breakers, Petri dishes, endoscopes and so on.
|
|
|
| |
|
|
|
